The Yagi Antenna is a powerful and efficient solution designed to enhance wireless signal strength and improve overall connectivity. With a frequency range of 617MHz to 4000MHz, this antenna is compatible with a wide range of wireless networks, making it suitable for various applications, including 4G LTE, 5G, Wi-Fi, and more. Its high-gain capabilities of 8dBi for 617-960MHz and 11dBi for 1710-4000MHz allow for strong and reliable signal transmission and reception, ensuring that you can stay connected with ease.
Key Features:
- Wide Frequency Range: The Yagi Antenna operates within a broad frequency range of 617MHz to 4000MHz, making it versatile and adaptable to different wireless networks and technologies.
- High Gain Performance: With a gain of 8dBi for the lower frequency band (617-960MHz) and 11dBi for the higher frequency band (1710-4000MHz), this antenna provides a significant boost to your signal strength and extends the reach of your wireless network.
- Vertical Polarization: The Yagi Antenna features vertical polarization, allowing for focused signal transmission and reception in a specific direction. This characteristic makes it ideal for long-range communication and point-to-point connections.
- N Female Connector: Equipped with an N Female connector, the Yagi Antenna ensures a secure and reliable connection to compatible wireless devices or network equipment.
- Sturdy Construction: Built with durability in mind, the Yagi Antenna is designed to withstand various weather conditions, making it suitable for both indoor and outdoor installations.
- Easy Mounting: The antenna comes with mounting hardware, simplifying the installation process. It can be easily mounted on walls, poles, or other suitable structures.
- Ideal for Rural Areas: If you reside in a rural area with limited network coverage, the Yagi Antenna can be a game-changer, as it can capture weaker signals and amplify them, providing you with improved connectivity.
Technical Specifications:
| Items | Specifications | |||
|---|---|---|---|---|
| Model NO | SE-YA-0640-V81101-NF | |||
| Frequency Range(MHz) | 617-698 | 698-960 | 1710-2700 | 3300-4000 |
| Gain(dBi) | 8.0 ± 0.5 | 9.5 ± 0.5 | 11.0 ± 0.5 | 11.5 ± 0.5 |
| VSWR | ≤ 2.0 | ≤ 2.0 | ≤ 1.5 | ≤ 1.5 |
| Polarization Type | Vertical | |||
| Front to Back Ratio(dBi) | ≥ 15 | ≥ 15 | ≥ 15 | ≥ 15 |
| Vertical Beamwidth | 105° | 95° | 78° | 59° |
| Horizontal Beamwidth | 87° | 68° | 56° | 48° |
| PIM(IM3) | ≤ -107 dBm @ 2 x 33 dBm | |||
| Max Power | 50 W | |||
| Input Impendence | 50 Ω | |||
| Operating Temperature | -40 ℃ to +65 ℃ | |||
| Relative Humidity | 5 to 95% | |||
| Lightning Protection | DC ground | |||
| Rated Wind Velocity | 210 km/h | |||
| Connector Type | N-Female | |||
| Weight | 0.87 Kg | |||
| Dimensions | 440 x 210 x 65 mm (without connector) | |||
| Radome Material | Uv-Protected ABS | |||
| Radome Color | White | |||
| Mounting Hardware | Φ 35 - Φ 50 mm | |||
