The Twisted Waveguide is a cutting-edge optical device that redefines the possibilities of light manipulation. With its innovative twisted structure, this waveguide enables precise control and modulation of light signals, making it a groundbreaking technology in various fields, including telecommunications, quantum computing, and sensing applications. In this product description, we will explore the key features and advantages of the Twisted Waveguide, showcasing its potential to revolutionize the way we harness and exploit light for diverse applications.
Key Features
- Twisted Architecture: The most remarkable feature of this waveguide lies in its unique twisted architecture. Unlike conventional straight waveguides, the Twisted Waveguide employs a helical shape that enables unprecedented control over the propagation of light. This twist imparts an orbital angular momentum to the light, providing an additional degree of freedom for manipulating optical signals.
- Enhanced Light-Guiding Properties: By skillfully manipulating the wavefront of light, the Twisted Waveguide exhibits exceptional light-guiding properties. It allows for efficient light confinement, reducing scattering and enabling the waveguide to transmit light over longer distances with minimal loss.
- Mode Diversity: The twisted structure facilitates multiple modes of light propagation, empowering researchers and engineers to tailor the waveguide’s behavior to specific applications. This mode diversity opens up exciting possibilities for advanced optical signal processing and quantum communication systems.
Technical Specifications
| Type | National standard | Frequency range(GHz) | Standing wave ratio | Standard length(mm) | Minimum size(mm) | Flange | Material | Plating |
|---|---|---|---|---|---|---|---|---|
| SE-430WTA..PM | BJ22 | 1.72-2.61 | ≤1.10 | 440 | 150 | FDP/FDM | Aluminium | Oxidation |
| SE-340WTA..PM | BJ26 | 2.17-3.30 | ≤1.10 | 400 | 140 | FDP/FDM | Aluminium | Oxidation |
| SE-284WTA.. .PM | BJ32 | 2.60-3.95 | ≤1.10 | 300 | 120 | FDP/FDM | Aluminium | Oxidation |
| SE-229WTA..PM | BJ40 | 3.22-4.90 | ≤1.10 | 200 | 90 | FDP/FDM | Aluminium | Oxidation |
| SE-187WTA..PM | BJ48 | 3.94-5.99 | ≤1.10 | 200 | 70 | FDP/FDM | Aluminium | Oxidation |
| SE-159WTA.. .PM | BJ58 | 4.64-7.05 | ≤1.10 | 200 | 70 | FDP/FDM | Aluminium | Oxidation |
| SE-137WTA..PM | BJ70 | 5.38-8.17 | ≤1.10 | 100 | 60 | FDP/FDM | Copper | Silvering |
| SE-112WTA..PM | BJ84 | 6.57-9.99 | ≤1.10 | 100 | 50 | FDP/FDM | Copper | Silvering |
| SE-90WTA..PM | BJ100 | 8.20-12.40 | ≤1.10 | 100 | 45 | FDP/FDM | Copper | Silvering |
| SE-75WTA..PM | BJ120 | 9.84-15.0 | ≤1.10 | 100 | 40 | FDP/FDM | Copper | Silvering |
| SE-62WTA..PM | BJ140 | 11.9-18.0 | ≤1.10 | 100 | 40 | FDP/FDM | Copper | Silvering |
| SE-51WTA..PM | BJ180 | 14.5-22.0 | ≤1.10 | 60 | 35 | FDP/FDM | Copper | Silvering |
| SE-42WTA..PM | BJ220 | 17.6-26.7 | ≤1.10 | 60 | 35 | FDP/FDM | Copper | Silvering |
| SE-34WTA..PM | BJ260 | 21.7-33.0 | ≤1.10 | 60 | 35 | FDP/FDM | Copper | Silvering |
| SE-28WTA..PM | BJ320 | 26.5-40.0 | ≤1.10 | 50 | 30 | FDP/FDM | Copper | Silvering |
| SE-22WTA.. | BJ400 | 32.9-50.1 | ≤1.15 | 50 | 30 | FUGP | Copper | Gilding |
| SE-14WTA.. | BJ500 | 32.9-59.6 | ≤1.15 | 50 | 30 | FUGP | Copper | Gilding |
| SE-18WTA... | BJ20 | 49.8-75.8 | ≤1.15 | 50 | 25 | FUGP | Copper | Gilding |
| SE-12WTA.... | BJ740 | 60.5-91.9 | ≤1.15 | 50 | 25 | FUGP | Copper | Gilding |
| SE-10WTA.. | BJ900 | 73.8-112 | ≤1.15 | 50 | 25 | FUGP | Copper | Gilding |
